Specifications Parameter | Length （mm) | Height （mm) | Thickness （mm) | Units PerStrip （PCS） | Step Spacing （mm) | Pin Spacing （mm） | Cup depth （mm） | Cup bottom diameter | Cup caliber | Texture of Material |
2002-2T1 | 152.4 | 25.40 | 0.5 | 20 | 7.62 | 2.54 | 0.25 | 0.60 | 1.15 | SPCC |
2002-2T1 | 152.4 | 25.40 | 0.5 | 20 | 7.62 | 2.28 | 0.25 | 0.60 | 1.15 | SPCC |
2002R08-1 | 152.4 | 25.40 | 0.5 | 20 | 7.62 | 2.54 | 0.37 | 0.55 | 1.07(1.3) | SPCC |
2002LD | 152.4 | 25.40 | 0.5 | 20 | 7.62 | 2.54 | 0.35 | 0.60 | 1.09(1.3) | SPCC |
2004L24-1 | 152.4 | 36.08 | 0.5 | 20 | 7.62 | 2.54 | 0.25 | 0.60 | 1.15 | SPCC |
2004LD-L01 | 152.4 | 36.08 | 0.5 | 20 | 7.62 | 2.54 | 0.50 | 0.53 | 1.30 | SPCC |
2004LD-L09-9 | 152.4 | 36.08 | 0.5 | 20 | 5.08 | 2.54 | 0.25 | 0.60 | 1.15 | SPCC |
2004-5A | 152.4 | 36.12 | 0.5 | 20 | 5.08 | 2.54 | 0.30 | 0.55 | 0.92(1.05) | SPCC |
2003L23 | 152.4 | 36.08 | 0.5 | 20 | 7.62 | 2.54 | 0.35 | 0.70 | 1.4 | SPCC |
2003CS | 152.4 | 51.08 | 0.5 | 20 | 7.62 | 2.54 | 0.56 | 0.50 | 1.52 | SPCC |
2003S11 | 152.4 | 36.08 | 0.5 | 20 | 7.62 | 2.54 | 0.5 | 0.55 | 1.45 | SPCC |
2007J7 | 152.4 | 36.08 | 0.5 | 20 | 7.62 | 2.54 | 双平头、平台宽￠1.0 | SPCC | ||
2009-6 | 152.4 | 37.30 | 0.5 | 20 | 7.62 | 2.54 | 0.25 | 1.12*0.6 | 1.50 | SPCC |
